Factory Directly Supplying High Strength Stainless Steel Grating Drain Cover with Natural Surface Treatment

Steel Bar Grating, also known as welded steel bar grate is extremely strong and durable for all load bearing applications and is primarily used for pedestrian and light vehicle traffic.
Steel Bar Grating is available in a variety of bearing bar spacing and thickness depending on applications and load requirements.
Available in either smooth top or serrated for slip resistance.

Stormwater drains cover are essential systems designed to efficiently manage excess rainwater, preventing flooding and water accumulation in urban areas. Constructed from high-quality materials, these drains are durable and designed to withstand harsh weather conditions, ensuring long-term performance.

Key features include a streamlined design that promotes optimal water flow, customizable sizes to fit various applications, and a debris-resistant grate that minimizes clogging. Ideal for use in roads, parking lots, and residential properties, our stormwater drains enhance drainage efficiency and protect infrastructure from water damage.

Usual Specification of Steel Grating
Material Standard	ASTM A36, A1011, A569, Q235, S275JR, Stainless steel 304, Mild steel & Low carbon steel, etc
Bearing Bar (width x thickness)	25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4.5, 30x5, 40x5, 50x5, 65x5, 75x6,75x10, 100x10mm, etc. I Bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3, etc US Standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x1/4", 1 1/4"x1/4", 1 1/2"x1/4", 1"x1/8", 1 1/4"x1/8", 1 1/2"x1/8", etc.
Bearing Bar Pitch	12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41, 41.25, 60, 80mm, etc. US Standard: 19-W-4, 15-W-4, 11-W-4, 19-W-2, 15-W-2, etc.
Twisted Cross Bar Pitch	38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2"&4", etc.
Surface treatment	Untreated(black), hot dipped galvanized, powder coated, electroplate, painting or as per customers' requires.
Grating Types	Plain/Smooth, Serrated/teeth, I bar, serrated I bar, Serrated I bar
Exporting Packing Ways	LCL(Less than one container load): packed with plastic film + wooden pallets; FCL(full container load): nude packing Other special packages: according to customers' request.
Special Specification could be ordered as per your requires!
